Single Rectangle Lighting System (2.4M x 4.8M)

Name: Single Rectangle Lighting System (2.4M x 4.8M)
Brand: HexSpace
Price: 749.0 AUD
Availability: InStock
Rating: 5.0 (85 reviews)

$749.00

or 4 interest-free payments with Afterpay or Klarna

Design & Engineered for Australia
Aluminium Housing – Strong, safer & better heat dissipation
Long 3-Pin Design – With earth wire for extra protection
High CRI >90 – Flicker-free & glare-free
50,000+ Hours – Premium LEDs & stable driver for long-term performance

Hanging installation? Add suspension wires

This system needs a minimum of 12 wires for suspended mounting.

Add Wire Kits

Order today and receive it between and

✅ SAA & RCM Certified | 🇦🇺 EESS Responsible Supplier E20158 | 🛡️ Up to 5 Years Warranty | 🚚 Free Shipping Over $300

Description
Installation
Colour Temperature
Specifications
Shipping & Warranty
Custom Services
FAQ

Description

Single Rectangular Grid LED Light for Compact Garages and Work Areas

The Single Rectangular is our most compact linear LED system, with an overall footprint of about 2.4m x 4.8m. One clean rectangular frame throws bright, even light across a single bay, a home garage corner, a workbench or a small shop area. If you want a sharp, modern ceiling light without committing to a full grid, this is the easiest place to start.

Why choose the Single Rectangular

One rectangular LED frame for focused, glare-free light over a compact space
Aluminium housing for strength, better heat dissipation and a longer service life
High CRI (85+) so paint, tools and detail work show true-to-life colour
Flicker-free light that stays comfortable through long sessions
Four colour temperatures: 6500K daylight, 5000K cool white, 4000K neutral and 3000K warm white

Specifications

Overall size: approximately 2.4m x 4.8m
Layout: single rectangular frame
Colour temperature: 3000K, 4000K, 5000K or 6500K (choose one)
Housing: aluminium
Colour rendering: CRI 85+
Rated life: 50,000 hours
Installation: plug-in or hardwired, AU and NZ plug included

Which size is right for you

Lighting a larger area? Step up to the Double Rectangular for a two-frame layout, or the Triple Rectangular for full workshop and double-garage coverage. You can compare the full range on our garage lighting collection.

Installation

The system supports both plug-in and hardwired setups, so you can match it to your space and local wiring. It ships with an AU and NZ standard plug and safe, easy-connect wiring.

FAQ

Is the Single Rectangular enough for a full garage?
It suits a compact single bay or a focused work zone. For a standard single garage or larger, most customers prefer the Double or Triple layout for more even coverage.

Can I change the colour of the light?
Yes. Choose one of four colour temperatures at checkout, from warm 3000K through to bright 6500K daylight.

Do I need an electrician?
The light supports plug-in use out of the box and can also be hardwired. For hardwired installs, follow your local electrical requirements.

Installation

Colour Temperature

6500K	Brightest daylight. Ideal for detailing, barbershops, workshops, and garages with DIY or hands-on tasks.Most Popular
5000K	Clean daylight. Great for everyday garage use, parking, storage, and home gyms.
4000K	Neutral white. Versatile for offices, retail, and mixed-use spaces.
3000K	Warm white. Best for relaxed environments, showrooms, and retail displays.

Specifications

System Wattage	192W
Product Dimensions	4800mm * 2400mm
Luminous Output	Approx. 21,120 - 23,040 lm
Light Tubes	12 (1178mm)
Material	Aluminium housing with polycarbonate diffuser
CRI	>90
Luminous Efficiency	110-120 lm/W
Working Lifetime	50,000+ hours
Ingress Protection	IP54 (dust and splash resistant)
Input Voltage	240V AC, 50/60Hz
Colour Temperature	6500K / 5000K / 4000K / 3000K
Beam Angle	180 degrees, non-dimmable
Safety and Compliance	SAA, RCM, CE, UL, ROHS
Plug Type	AU/NZ 3-pin with earth wire
Mounting	Surface mount or suspension (wire kit optional)
Suspension Wires Needed	12 minimum (sold separately)
Installation	Plug and play quick connect system

Shipping & Warranty

Shipping

Please allow 1–2 business days for order processing. Once dispatched, most orders are delivered within 5–7 business days, remote areas may take longer.
Some orders may be shipped in multiple parcels from different warehouses, depending on stock availability and your delivery address.
Tracking information will be provided for each shipment. We do our best to ensure fast and reliable delivery every time.

Warranty

Our hexagon lights are covered by up to a 5-year limited warranty from the date of purchase. For full details see our warranty policy, or contact us at info@hexspace.com.au.

Custom Services

Looking for customized hexagon lighting solutions? Contact us at info@hexspace.com.au and let us know the dimensions of your desired lighting area. Our team is ready to assist with tailored designs to suit your space perfectly!

FAQ

What size system do I need?

As a rough guide: 5-14 grids for a single garage (3m x 6m),two 5-14 grids or a 23 grid systems for a double garage (6m x 6m). Check the Specifications tab for exact dimensions. Contact us for layout advice.

Which colour temperature should I pick?

6500K — daylight, Ideal for detailing, barbershops, workshops, and garages with DIY or hands-on tasks. 5000K — Clean daylight. Great for everyday garage use, parking, storage, and home gyms. 4000K — Neutral white. Versatile for offices, retail, and mixed-use spaces. 3000K — Warm white. Best for relaxed environments, showrooms, and retail displays. Not sure? Go with 5000K or 6500K.

Where does the power cable come out?

You choose. It connects at any outer corner of the grid, so you can run it towards your nearest power point.

Do I need an electrician?

Plug-in: no, just plug into a 240V outlet. Hardwired (no visible cables): yes, a licensed electrician is required by law in Australia and New Zealand.

Is this easy to install?

Yes. Assemble on the floor, test, mount to ceiling. Most customers finish in 2 to 4 hours. See our Installation Guide for the full walkthrough.

How can I mount the lights?

Three options: surface-mount to ceiling with screws (most common), wall-mount for a feature wall look, or suspend from the ceiling using our suspension wire kit. Every connector has built-in screw slots so no extra brackets are needed.

Is this safe and certified?

SAA approved and RCM certified. Our entire system uses 3-pin connectors with earth wire — every tube, every connector, not just the power plug.

Can I add more hexagons later?

Yes. The system is modular. Buy another kit and connect it to your existing setup.

What happens if a tube stops working?

Only that tube goes dark the rest stays on. Just swap it out. We offer a Replacement Tube Pack in our accessories collection.
